Zener Diode Characteristics Trainer (4 Analog MR-65 Meters)

Product Code: 3510819

SCOPE OF LEARNING:
•    Study of V-I Characteristics of Zener Diode in Forward and Reverse Bias.
TECHNICAL SPECIFICATIONS:
Analog Meters:
•    Ammeter 15mA DC
•    Ammeter 150uA DC.
•    Voltmeter 3V DC.
•    Voltmeter 15V DC.
Power Supplies:
•    DC Supply IC Regulated 0-3V DC, 150mA.
•    DC Supply IC Regulated 0-15V DC, 150mA.
•    Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
•    Zener Diode 5.1V
•    Zener Diode 6.2V
•    Zener Diode 8.2V
•    Voltage Control through Potentiometer.
SALIENT FEATURES:
•    Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
•    Fuse for Short Circuit protection
•    Instruction manual.
•    Connections are brought out through 4mm Colored Sockets.
•    Patch Cords 4mm.
•    The trainer is housed in ABS Plastic cabinet.
•    Size of the trainer set 10”x8”
OPTIONAL ACCESSORIES:
•    Multimeter
