Stepper Motor Control using 8051 Microcontroller

Product Code: 3511751

SCOPE OF LEARNING:
•    Study of Speed  Control  of Stepper Motor by Interfacing Microprocessor
•    TECHNICAL SPECIFICATIONS:
Power Supply:
•    IC regulation in controller circuit power supplies
•    Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
•    TTL circuit for single stepping and free run mode with frequency generator <10-100 Hz
•    Wobble mode
•    Direction selector
•    LED indicators for phase sequence observation
•    12V, 1A/phase, 2.0 kg/cm torque, 1.8 degree stepper motor, Up interface
•    Calibrated dial for position monitoring
SALIENT FEATURES:
•    Front panel built with high class insulated Printed Circuit on Metal Board sheet with well printed circuits and symbols.
•    Instruction manual.
•    Connections are brought out through 4mm Sockets.
•    Patch Cords 4mm.
•    The trainer is housed in Metal cabinet.
•    Size of the trainer set 18”x7” and 11x7 (Set of 2 Trainers)
PACKING LIST:
•    8085 Microprocessor Trainer
•    Stepper Motor Control Trainer
•    Stepper Motor Unit
