RC Coupled Amplifier Trainer (Single Stage) With Sine Wave and AC Millivoltmeter

Product Code: 3512335

SCOPE OF LEARNING:
•    Study of Common Emitter Amplifier Using Transistor
TECHNICAL SPECIFICATIONS:
Digital Meters:
•    AC Millivoltmeter 200mV
•    AC Voltmeter 20V
Power Supplies:
•    Sine Wave Generator 0-100KHz.
Power Supplies:
•    DC Power Supply IC Regulated +15V DC, 150mA.
•    Operated on Mains power 230V, 50Hz +10%
Components are mounted on the panels are:
•    Transistors
•    Resistors
•    Capacitors
•    Load Resistor through Rotary Switch
SALIENT FEATURES:
•    Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
•    Fuse for Short Circuit protection
•    Instruction manual.
•    Connections are brought out through 4mm Colored Sockets.
•    Patch Cords 4mm.
•    The trainer is housed in ABS Plastic cabinet.
•    Size of the trainer set 15”x11”
OPTIONAL ACCESSORIES:
•    No
