OP-AMP As Inverting, Non-Inverting, Integrator, Differentiator, Summing, Difference, Average, Scaling & Differential Amplifier

Product Code: 3512312

SCOPE OF LEARNING:
•    Study of Integrator using Op-amp
•    Study of Differentiator using Op-amp
•    Study of Inverting Amplifier using Op-amp
•    Study of Non Inverting Amplifier using Op-amp
•    Study of Summing Amplifier using Op-amp
•    Study of Difference Amplifier using Op-amp
•    Study of Average Amplifier using Op-amp
•    Study of Scaling Amplifier using Op-amp
•    Study of Differential Amplifier using Op-amp
TECHNICAL SPECIFICATIONS:
Power Supplies:
•    Dual DC Power Supply IC Regulated +15V DC, 150mA.
•    Fixed IC Regulated +5V DC, 150mA.
•     DC Power Supply IC Regulated 0-12V DC, 150mA.
•    DC Power Supply IC Regulated 0-12V DC, 150mA.
•    Operated on Mains power 230V, 50Hz +10%
Digital Meter:
•    Voltmeter 20V
Components are mounted on the panels are:
•    741 IC (Op-amp)
•    Resistors
•    Capacitors
SALIENT FEATURES:
•    Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
•    Fuse for Short Circuit protection
•    Instruction manual.
•    Connections are brought out through 2mm Colored Sockets.
•    Patch Cords 2mm.
•    The trainer is housed in ABS Plastic cabinet.
•    Size of the trainer set 12”x8”
OPTIONAL ACCESSORIES:
•    Multimeter
