Multiplexer and Demultiplexer Trainer Kit

Product Code: 3510591

SCOPE OF LEARNING:
•    8:1 Multiplexer
•    1:8 Demultiplexer
•    4:1 Multiplexer
•    4:1 Demultiplexer
•    TECHNICAL SPECIFICATIONS:
Power Supplies:
•    DC Power Supply +5V,150mA
•    Operated on Mains power 230V, 50Hz +10%
•    Technical specifications:
•    Twenty One independent logic level inputs to select High / Low TTL levels, each with a LED to indicate high / low status and termination.
•    8 independent buffered logic level indicators for High / Low status
•    And gate operation given onboard.
•    IC for Multiplexing 74151 and 74153 is provided on board with Combinational Circuit.
•    IC for Demultiplexing 74139 and 74138 is provided on board with Combinational Circuit.
SALIENT FEATURES:
•    Front panel built with high class insulated Printed Circuit Board sheet with well printed circuits and symbols.
•    Instruction manual.
•    Connections are brought out through 2mm Sockets.
•    Patch Cords 2mm.
•    The trainer is housed in ABS Plastic cabinet.
•    Size of the trainer set 12”x8”
